2 Guns 44kW European Standard Bussiness AC Charger444
Dedicated for best quality innovations
2 Guns 44kW European Standard Bussiness AC Charger444
2 Guns 44kW Type 2 INFORE ENVIRO AC EV Charging Station Fast Charging
Highlights :
- 44kW
- 2 Guns（CCS1/CCS2/GBT/CHADEMO/NACS)
- Floor-stand
- 4.3-inch LCD screen
- OCPP 1.6J
- IP54
- CE
Description
| 44kW European Standard Bussiness AC Charger | ||
| | High efficiency, reliable and stable performance | | ||
| General Requirements | ||
| Charging capacity 44kW | ||
| AC supply system | Three-phase,5 wire AC system | |
| Input voltage | AC 400V+15%(ENC) | |
| Input frequency | 50/60±3Hz | |
| Number of connector | 2 | |
| Output voltage | AC 400V±15%(ENC) | |
| Output current | Max.32 Amp | |
| Output connector type | IEC 62196 2017,IEC 61851 2017.SAE J1772.etc | |
| Connector mounting | Indoor use | |
| Communication | ||
| Communication | OCPP 1.6/OCPP 2.0.1(optional) | |
| Connectivity | Ethernet/3G/4G/WIFl (optional) | |
| Metering | Grade 1 with MID | |
| Interaction | ||
| Emergency stop switch | Support | |
| Display | 4.3” touch screen (optional ) | |
| Startup mode | QR Code/RFID Card/ Password (optional) | |
| Safety | ||
| Enclosure rating | IP54 | |
| Cooling | Natural cooling | |
| Safety | Over current,under voltage,residual current,surge protection,leakage protection,short circuit,over temperature,etc. | |
| Certification | CE | |
| Environment parameters | ||
| Ambient temperature range | -25°C~+55°C | |
| Ambient humidity | 5 to 95% | |
| Storage temperature | -40°C~+70°C | |
| Physii call properties | ||
| Net weight | 67.5kg | |
| Gross weight | 87.5kg | |
| Product demension | 340*201*1500mm | |
| Package demension | 550*350*1665mm(single package) | |
| Cable length(m) | 5 | |
Description
Specification
Packing
Description
| 44kW European Standard Bussiness AC Charger | ||
| | High efficiency, reliable and stable performance | | ||
| General Requirements | ||
| Charging capacity 44kW | ||
| AC supply system | Three-phase,5 wire AC system | |
| Input voltage | AC 400V+15%(ENC) | |
| Input frequency | 50/60±3Hz | |
| Number of connector | 2 | |
| Output voltage | AC 400V±15%(ENC) | |
| Output current | Max.32 Amp | |
| Output connector type | IEC 62196 2017,IEC 61851 2017.SAE J1772.etc | |
| Connector mounting | Indoor use | |
| Communication | ||
| Communication | OCPP 1.6/OCPP 2.0.1(optional) | |
| Connectivity | Ethernet/3G/4G/WIFl (optional) | |
| Metering | Grade 1 with MID | |
| Interaction | ||
| Emergency stop switch | Support | |
| Display | 4.3” touch screen (optional ) | |
| Startup mode | QR Code/RFID Card/ Password (optional) | |
| Safety | ||
| Enclosure rating | IP54 | |
| Cooling | Natural cooling | |
| Safety | Over current,under voltage,residual current,surge protection,leakage protection,short circuit,over temperature,etc. | |
| Certification | CE | |
| Environment parameters | ||
| Ambient temperature range | -25°C~+55°C | |
| Ambient humidity | 5 to 95% | |
| Storage temperature | -40°C~+70°C | |
| Physii call properties | ||
| Net weight | 67.5kg | |
| Gross weight | 87.5kg | |
| Product demension | 340*201*1500mm | |
| Package demension | 550*350*1665mm(single package) | |
| Cable length(m) | 5 | |
Specification
Packing
